JMC cargo truck 4Ton

Vehicle name

Cargo truck

Vehicle chassis model

JX1041TG25

Weight parameter

Rated load

（kg）

1995

Overall dimension (mm)

5955×1880×2140

Curb weight

（kg）

2315

Box dimension

(mm)

4220×1780×380

Actual max.load   capacity（kg）

4000-5000

Wheel base

(mm)

3360

Engine

Model

JX493ZLQ5

Description of engine

4 cylinders,in line,turbocharged,water-cooled, inter-cooled

Max.power（kw/hp）

85/116

Fuel type

Diesel

Performance

Max. vehicle speed

(km/h)

100

Running angle(°)

Approach angle

27

F/R overhang(mm)

1065/1530

Departure angle

17.5

Emission standard

Euro V

Drive type

4X2

Description of gearbox

JC528T6, 5 forward gears, 1 reverse gear

Steering type

LHD

Clutch

Diaphragm spring clutch

Brake system

Hydraulic brake system

Specification

of tire

7.00R16

Number of tires

6+1

Frame

Stamping riveted structure

Number of leaf spring

7/5+6

Cabin

Single row, 2 passengers allowable
